Digits | 5 |
Number format | 8.8.8.8.8. |
LED type | 7-segment ultrabright LED elements, viewing angle 120° |
Height of characters | 57 mm |
Type of displaying elements | red |
Readability range | 23 m |
Frame colour | platinum matt |
Frame type | aesthetic anodized aluminum frame |
Class of protection | IP 52 |
Communication interface | serial line RS485 or RS232 with galvanic separation; other options: Profibus DP, Ethernet TCP/IP, BCD 24V, LonWorks FTT-10A, analog inputs (0-10V, 0-20mA, 4-20mA, counter input) and others on request |
Communication protocol | ELEN, Modbus RTU, Schenck DDP 8850, DDP 8861 (Disomat B, Disomat F), Intecont plus, Orbit Controls, LonTalk and others upon request |
Power supply | 110/230 VAC, 50 Hz |
Power consumption | 8 W |
Dimensions | 430 mm x 160 mm x 76 mm |
Weight | 4,2 kg |
