| Measured temperature range |
-55°C to +120°C |
Communication interface
|
1-WIRE
|
Power supply
|
5 VDC (powered directly from the display)
|
| Probe dimensions |
diameter 6 mm, length 60 mm |
Probe material
|
stainless steel
|
Box dimensions
|
7,6 cm x 3,5 cm x 2,0 cm |
| Enclosure protection class |
IP 68 (suitable to be used indoor or outdoor) |
Connector
|
industrial Binder
|
| Cable diameter |
4,3 mm |
| Cable material |
silicon rubber, blue color |
| Cable, temperature range |
-60°C to +200°C |
Cable length*
|
2 m |
* It is possible to supply temperature sensor with cable length up to 5 meters max. In case of longer installation distance it is possible to order another version of temperature sensor, RS485 type.
